Vivotek ND8422P User Manual

VIVOTEK - Built with Reliability
User's Manual - 133
2. Restore - If you have a previously-saved prole, you can restore your previous conguration.
Click the Restore button.
A le location window will prompt. Locate the backup le, and click Open. The Restore
process will take several minutes to complete, and system operation will be interrupted during
the process.
3. Restore Default - There are two kinds of defaults for the NVR systems: System defaults and
factory defaults.
The system defaults can be restored using the reset button on the system panel (press for
5 seconds) . This applies when users forget about its IP address or login password, while
most other operation details will remain unchanged.
The factory defaults (operated on this window) restores to its primitive state before shipping,
and hence users' congurations (such as host name, IP address, and layout settings) will be
erased.
Click Restore to restore your system defaults. A warning message will appear. Click OK to
proceed. The Restore process will take several minutes to complete, and system operation
will be interrupted during the process.
A successful operation will produce the following message.

Vivotek ND8422P Specifications

General

HDD capacity	6144 GB
HDD interface	eSATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
DVI-I ports quantity	0
USB 2.0 ports quantity	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	1
Power consumption (max)	120 W
Certification	CE, LVD, FCC, VCCI, C-Tick, UL
LED indicators	HDD, Power, Status, eSATA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Maximum resolution	2560 x 1920 pixels
Alarm input channels	8
Video input channels	16 channels
Alarm output channels	4
Video formats supported	H.264
Resolution at capture speed	1920x1080@120fps
Minimum RAM	2 GB

Weight and Dimensions

Depth	311 mm
Width	360 mm
Height	44 mm
Weight	2700 g
