General| HDD capacity | 6144 GB |
|---|---|
| HDD interface | eSATA |
| Maximum storage capacity | 12 TB |
| Number of HDDs supported | 2 |
| DVI-I ports quantity | 0 |
| USB 2.0 ports quantity | 3 |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Power consumption (max) | 120 W |
| Certification | CE, LVD, FCC, VCCI, C-Tick, UL |
| LED indicators | HDD, Power, Status, eSATA |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Maximum resolution | 2560 x 1920 pixels |
| Alarm input channels | 8 |
| Video input channels | 16 channels |
| Alarm output channels | 4 |
| Video formats supported | H.264 |
| Resolution at capture speed | 1920x1080@120fps |
| Minimum RAM | 2 GB |
Weight and Dimensions| Depth | 311 mm |
|---|---|
| Width | 360 mm |
| Height | 44 mm |
| Weight | 2700 g |
