Vivotek ND8422P User Manual

VIVOTEK - Built with Reliability
User's Manual - 153
Each hard drive installed into the system will be considered as a candidate for composing a
single-disk volume.
Single disk: The single disk conguration provides no fault tolerance. The system stores video
recordings to one or more single disk volumes in a consecutive order.
5-4-1. Storage - Volume
5-4. Storage
Single disks
Disk 1 Disk 1
Each single disk volume contains one disk drive.
If you remove a disk drive and insert it into a different drive bay, the system will consider it as a
new and different disk drive.
IMPORTANT:

Vivotek ND8422P Specifications

General

HDD capacity	6144 GB
HDD interface	eSATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
DVI-I ports quantity	0
USB 2.0 ports quantity	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	1
Power consumption (max)	120 W
Certification	CE, LVD, FCC, VCCI, C-Tick, UL
LED indicators	HDD, Power, Status, eSATA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Maximum resolution	2560 x 1920 pixels
Alarm input channels	8
Video input channels	16 channels
Alarm output channels	4
Video formats supported	H.264
Resolution at capture speed	1920x1080@120fps
Minimum RAM	2 GB

Weight and Dimensions

Depth	311 mm
Width	360 mm
Height	44 mm
Weight	2700 g
