User's Manual - 15
16-Channel Connections (ND8422P)
LAN/WAN
PoE
x8
x8
AW-GEV-264A PoE switch
ND8422P NVR
Uplink
The ND8422P supports the connections to 16 cameras. However, the NVR comes with 8 PoE
ports. The other 8 cameras should be powered by other devices, e.g., a PoE switch. The other 8
cameras should then be detected via the NVR’s Gb/s Ethernet uplink to the local network.
