Vivotek ND8422P User Manual

VIVOTEK - Built with Reliability
170 - User's Manual
4-5. HTTP - An event message is sent to an HTTP server on the occurrence of an event. The
URL format for the HTTP server address is http://host:port[abs_path]. The applicable
characters for the abs_path are: [0-9][a-z][A-Z][-][.][:][/][?][&][@][_][=].
If you need to log in to HTTP server, enter the User name and password for access to
that account.
The user name can be composed of 64 numeric or alphabetic characters and symbols
including [0-9][a-z][A-Z][_][ ][-][.][,].

Vivotek ND8422P Specifications

General

HDD capacity	6144 GB
HDD interface	eSATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
DVI-I ports quantity	0
USB 2.0 ports quantity	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	1
Power consumption (max)	120 W
Certification	CE, LVD, FCC, VCCI, C-Tick, UL
LED indicators	HDD, Power, Status, eSATA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Maximum resolution	2560 x 1920 pixels
Alarm input channels	8
Video input channels	16 channels
Alarm output channels	4
Video formats supported	H.264
Resolution at capture speed	1920x1080@120fps
Minimum RAM	2 GB

Weight and Dimensions

Depth	311 mm
Width	360 mm
Height	44 mm
Weight	2700 g
