Chapter 4: List of function parameters - shorted
97
Example No. 3: Parameterisation for the control of the electric
motor of the crane
Installation procedure:
1./ connect the inverter, protections, connect the braking resistor, etc.
2./ connect the motor to the inverter (preferably without the clutch engaged - idle)
3./ set the motor parameters P0.00=0; P0.01=1 and P2.01;P2.02;P2.03;P2.04
4./ turn on automatic engine tuning P2.37=1
5./ the converter displays "Study" and we press START
6./ the converter is "paired" to the motor
7./ after the end of the autotuning, the inverter displays e.g. 50.0 Hz (set frequency)
Only then will we adjust the parameters according to the table below and connect the
control!
P0.00
G constant load
1
P0.01
SFVC control
1
P0.02
Select command channel
Through the input terminals
1
P0.04
Select the main frequency source X
06
P2.01
Rated motor power
Electric motor power 37 kW
37
P2.02
Rated motor voltage
Voltage V from nameplate
400
P2.03
Rated motor current
Current A from nameplate
P2.04
Rated motor frequency
Frequency Hz from the
nameplate
50
P2.37
Automatic tuning
1
P5.00
FWD function selection
RUN right at speed 1
1
P5.01
REV function selection
RUN left at speed 1
2
P5.02
S1 function selection
Not connected
9
P5.03
S2 function selection
Speed 2
12
P5.04
S3 function selection
Not connected
13
PC.00
Multiple function 0
Frequency in % for speed 1
20
PC.01
Multiple function 1
Frequency in % for speed 2
100
P6.02
RA-RB-RC relay output function (It is
needed to release the external brake)
Frequency reached
4
P8.21
The range of detection of the frequency
reached
About 3 Hz, but we indicate it
in %
12
P9.03
Activation of the integrated brake unit
0
If you turn on FWD/GND, the inverter will start to the right at speed 1
If you turn on REV/GND, the inverter will run to the left at speed 1
If you turn on both FWD/GND and S2/GND at the same time, the inverter will run
clockwise at speed 2
If you turn on both REV/GND and S2/GND at the same time, the inverter will run to the left
at speed 2
