Chapter 1: Technical parameters
16
1.12 Openings for mounting the external control panel
For models ..0004 to 0300 (i.e. 0.4kW - 30 kW) .................... 68,5 x 39 mm
For models..0370 and bigger (i.e. 37 kW and more) .............. 70 x 119 mm
Opening for the keyboard (single-line display)
Opening for the keyboard (two-line display)
