Chapter 5: Detailed description of parameters
193
The set voltage indicates the theoretical output voltage of the inverter. The measured
voltage indicates the actual output voltage measured by the instruments, such as the
multimeter.
Group D0: Monitoring parameters
The group of D0 parameters is used to monitor the condition of the inverter while it is
running. You can view the parameter values using a control panel that is suitable for
putting into operation or from a host computer via the communication interface.
Parameters D0.00 to D0.31 are monitoring parameters during run and stop defined by
parameters P7.03 and P7.04.
See the table for more details.
Function code
Parameter Name
Unit
D0.00
Run Frequency (Hz)
0.01Hz
D0.01
Set frequency (Hz)
0.01Hz
D0.02
Bus voltage (V)
0.1V
D0.03
Output Voltage (V)
1V
D0.04
Output current (A)
0.01A
D0.05
Output power (kW)
0.1 kW
D0.06
Output torque (%)
0.1%
D0.07
Input state of S
1
D0.08
Output state of M01
1
D0.09
Reserved
D0. 10
FIC voltage (V)
0.01 V
D0. 11
Reserved
D0. 12
Counter value
1
D0. 13
Length value
1
D0.14
Load Speed
1
D0. 15
PID setting
1
D0. 16
PID Feedback
1
D0. 17
PLC status
1
D0. 18
Input pulse frequency
0.01 kHz
D0. 19
Speed of the electric motor
rpm
D0.20
The remaining running time
0.1 min
D0.21
FIV voltage before correction
0.001V
D0.22
FIC voltage before correction
0.001V
D0.23
Reserved
D0.24
Linear speed
1 m/min
