VYBO Electric Vector V800 - Technical Parameters

3
1.1 Technical parameters
Parameter
VECTOR V 800
Power supply
Supply voltage
Input voltage range: 1 x 230 V AC ± 10%
3 x 400 V AC ± 10%
Power supply
frequency
Power supply frequency range 47 - 63 Hz
Standard functions
Control mode
V/F scalar control
SFVC vector control with open circuit
Maximum frequency
SFVC vector control: 0-320 Hz
V/F scalar control: 0-3200Hz
Carrier frequency
1 – 16 kHz
The carrier frequency is automatically adjusted based on
the load characteristic.
Input frequency
resolution
Digital setting 0.01 Hz
Analogy setting: maximum frequency x 0.025%
Initial torque
G type: 0.5 Hz/150% (SFVC)
P type: 0.5 Hz/100%
Speed range
1:100 (SFVC)
Stability of speed
± 0.5% (SFVC)
Torque control
accuracy
± 5% (SFVC)
Overload size
G type: 60s for 150% rated current, 3s for 180% rated
current
P type: 60s for 120% rated current, 3s for 150% rated
current
Increase of torque
Auto-boost or user manual boost 0.1% to 30.0%
V/F curve
Integrated with "C1" designation of class C1. Without
marking C2.
V/F separation
Linear V/F curve
Multi-point V/F curve
N-voltage V/F curve (multiple of 1.2-voltage, 1.4- voltage,
1.6- voltage, 1.8- voltage, modified)
Ramp modes
Two types: complete separation; half separation
Overload size
Linear curve
The ramp of S-curve type
Four sets of acceleration / deceleration in ranges of 0.0 -
6500.0 sec
