VYBO Electric Vector V800 - Group P5: Input Terminals X

Chapter 4: List of function parameters - shorted
62
Group P5: Input terminals
Function
code
Parameter name
Setting range
Default
setting
Attribute
P5.00
Function selection
FWD
0: No function
1: RUN forward (FWD)
2: Reverse RUN (REV)
3: Three-wire control
4: RUN forward JOG (FJOG)
5: Reverse RUN (RJOG)
6: Terminal UP
7: Terminal DOWN
8: Gradual stop
9: RESET of the fault (RESET)
10: Pause during RUN
11: Normally open (NO)
external error input
12: Multiple terminal 1
13: Multiple terminal 2
14: Multiple terminal 3
15: Multiple terminal 4
16: Terminal 1 for selecting
acceleration / deceleration time
17: Terminal 2 for selecting
acceleration / deceleration time
18: Switching frequency source
19: Reset via UP and DOWN (terminal,
control panel)
20: Command source switchover
terminal
21: Acceleration / deceleration disabled
22: Pause of PID
23: Recovering the PLC status
24: Swing pause
25: Counter input
26: Reset the counter
27: Length count input
28: Resetting the length
29: Torque control disabled
30: Pulse input (S3 only), option
31: Reserved
32: Immediate DC braking
33: Normal close (NC) input of external
fault (via S1 suitable for PTC)
1
★
P5.01
Select of funct. REV
4
★
P5.02
Select of function S1
9
★
P5.03
Select of function S2
12
★
