VYBO Electric Vector V800 - Group P7: Control Panel and Display

Chapter 5: Detailed description of parameters
144
The zero displacement coefficient of 100% FOV corresponds to 10V (or 20 mA). The
standard output refers to a value corresponding to an analogue output of 0 to 10 V (or 0 to
20 mA) without setting a zero shift or gain.
For example, if the analogue output is used as frequency of RUN and the output is
expected to be 8V at a maximum frequency of 3V, the gain is set to -0.50 and the zero
offset is set to 80%.
P6.17
M01 time of delay
Default
0.0 s
Setting range
0.0 s – 3600.0 s
P6.18
RA-RB-RC time of delay
Default
0.0 s
Setting range
0.0 s – 3600.0 s
These parameters are used to set the delay of M01 output terminals, relay 1 from time of
change to actual output.
P6.19 to P6.21: Reserved
P6.22
Selection of output terminal mode
Default
00000
Setting range
Units
M01 mode
0
Positive logic
1
Negative Logic
Tens
RA-RB-RC mode (0-1, the same as N101)
Used to define logic of M01, RA, RB, RC output terminals.
0: Positive logic
The output terminal is active when it is connected to the GND, and is inactive when
disconnected from the GND.
1: Negative Logic
The output terminal is inactive when it is connected to the GND, and is active when
disconnected from the GND.
Group P7: Control panel and display
P7.00
Correction power factor
Default
100.0
Setting range
0
0.0 - 200.0
It can adjust the output power by changing parameter P7.00, (output power can be
displayed helping with parameter D0.05)
