Chapter 4: List of funct
ion parameters
- shorted
89
Group PD: Communication parameters
Function
code
Parameter name
Setting range
Default
setting
Attribute
PD.00
Transfer speed
Units: MODBUS
0: 300 BPS
1: 600 BPS
2: 1200 BPS
3: 2400 BPS
4: 4800 BPS
5: 9600 BPS
6: 19200 BPS
7: 38400 BPS
8: 57600 BPS
9: 115200 BPS
Tens: Reserved
Hundreds: Reserved
Thousands: Reserved
0005
☆
PD.01
Data format
0: No parity, d
ata format <8, N,2>
1: Even parity, data
format <8, E,1>
2: Odd parity, d
ata format <8,0,1>
3: No parity, d
ata format <8, N,1>
Valid to MODBUS
3
☆
PD.02
Local address
1
- 247 : Broadcast ad
dress
1
☆
PD.03
Delay of reply
0ms - 20ms
2
☆
PD.04
Communication
timeout
0.0 (invalid) 0.1s
- 60.0s
0.0
☆
PD.05
Selection of the
MODBUS
transmission protocol
.X:
MODBUS proto
col
0: Non-standard MODB
US protocol
1: Standard MODBUS proto
col
X.
: Reserved
1
☆
PD.06
Current
communication
resolution
0: 0.01A
1: 0.10A
0
☆
Group PF: Reserved for service
94
96
