Chapter 4: List of function parameters - shorted
92
Function
code
Parameter name
Setting range
Default
setting
Attribute
C6.06
FI curve 4 maximum
C6.06 - +10.00V
10.00V
☆
C6.07
Corresponding FI 4
curve setting,
maximum
-100.0% - +100.0%
100.0%
☆
C6.08
The minimum of FI
curve 5
-10.00V - C6.10
0.00V
☆
C6.09
Corresponding FI 5
curve setting,
minimum
-100.0% - +100.0%
-100.0%
☆
C6.10
FI curve 5 inflexion 1
C6.08 - C6.12
3.00V
☆
C6.11
Corresponding curve
setting FI 5 inflexion 1
-100.0% - +100.0%
-30.0%
☆
C6.12
FI curve 5 inflexion 2
C6.10 - C6.14
6.00V
☆
C6.13
Corresponding curve
setting FI 5 inflexion 2
-100.0% - +100.0%
30.0%
☆
C6.14
FI curve 5 maximum
C6.12 - +10.00V
10.00V
☆
C6.15
Corresponding FI 5
curve setting,
maximum
-100.0% - +100.0%
100.0%
☆
C6.16
FIV jump point
-100.0% - 100.0%
0.0%
☆
C6.17
Amplitude of the FIV
jump
0.0% - 100.0%
0.5%
☆
C6.18
FIC jump point
-100.0% - 100.0%
0.0%
☆
C6.19
Amplitude of the FIC
jump
0.0% - 100.0%
0.5%
☆
Group C9: Special function PID
Function
code
Parameter name
Setting range
Default
setting
Attribute
C9.00
PID sleep frequency
0 - P0.12
0.00 Hz
0.00 Hz
C9.01
PID sleep time
0 - 5000.0 s
10.0 s
0.0 s
C9.02
PID wake-up value
0 - 100 %
60.0 %
0.0 %
