VYBO Electric Vector V800 - Group P8: Auxiliary Functions

Chapter 5: Detailed description of parameters
149
It is used to display the cumulative turn on time of the inverter. If the time reaches the set
on time (P8.17), the digital output 24 will switch ON.
P7.14
Total electricity
consumption
Default
---
Setting range
0 – 65 635 kWh
It is used to display the cumulative power consumption of the inverter.
Group P8: Auxiliary functions
P8.00
Jog (JOG) frequency
Default
2.00 Hz
Setting range
0.00 Hz – maximum frequency
P8.01
Jog acceleration (JOG)
Default
20.0 s
Setting range
0.0 s - 6500.0 s
P8.02
Jog deceleration (JOG)
Default
20.0 s
Setting range
0.0 s - 6500.0 s
These parameters are used to define the set frequency and acceleration / deceleration
time of the motor in JOG mode. The startup mode is "Direct start" (P1.00 = 0) and the stop
mode is "Deceleration to stop" (P1.10 = 0).
P8.03
Acceleration time 2
Default
According to the model
Setting range
0.0 s - 6500.0 s
P8.04
Deceleration time 2
Default
According to the model
Setting range
0.0 s - 6500.0 s
P8.05
Acceleration time 3
Default
According to the model
Setting range
0.0 s - 6500.0 s
P8.06
Deceleration time 3
Default
According to the model
Setting range
0.0 s - 6500.0 s
P8.07
Acceleration time 4
Default
According to the model
Setting range
0.0 s - 6500.0 s
P8.08
Deceleration time 4
Default
According to the model
Setting range
0.0 s - 6500.0 s
The 800 provides a total of four sets of acceleration / deceleration times, that is, the
previous three groups and the group defined in P0.08 and P0.09. The definitions of the
