Chapter 4: List of function parameters - shorted
57
P1.13
Braking DC current
at stop
0% - 100%
0%
☆
P1.14
DC braking time
0.0s - 100.0s
0.0s
☆
P1.15
Braking rate
0 – 100 %
100 %
☆
Group P2: Motor parameters
Function
code
Parameter name
Setting range
Default
setting
Attribute
P2.00
Motor type
selection
0: Common asynchronous motor
1: Variable frequency asynchronous
motor
0
★
P2.01
Rated motor
power
0.1kW - 500.0kW
by the
model
★
P2.02
Rated motor
voltage
1V - 2000V
by the
model
★
P2.03
Rated motor
current
0.01A - 655.35A
by the
model
★
P2.04
Rated motor
frequency
0.01 Hz – maximum frequency
by the
model
★
P2.05
Rated motor speed
1 rpm - 65535 rpm
by the
model
★
P2.06
Stator resistance
(asynchronous
motor)
0.001 Ω - 65.535 Ω
by the
model
★
P2.07
Rotor resistance
(asynchronous
motor)
0.001 Ω - 65.535 Ω
by the
model
★
P2.08
Leakage inductive
reactance
(asynchronous
motor)
0.01 mH - 655.35 mH
by the
model
★
P2.09
Mutual induction
(asynchronous
motor)
0.1 mH - 6553.5 mH
by the
model
★
