VYBO Electric Vector V800 - Example 2: First Start in SFVC Control Mode

Chapter 3 Operation
51
Example 2: first boot in SFVC control mode
P0.00=1
P0.01=1
P0.08=30 sec
P0.09=30 sec
P2.01=7,5 kW
P2.02=400 V
P2.03=14,2 A
P2.04=50 Hz
P2.05=2910 rpm
P9.00= 1
P9.01= 1.0
P9.03= 30
P9.12= 11
P9.13= 1
P2.37=1 (autotuning)
START
