Chapter 3 Operation
50
Example 1: first start in V/F control mode
P0.00= 2
P0.01= 0
P0.08= 120 sec
P0.09= 120 sec
P1.10= 1
P2.01= 7,5 kW
P2.02= 400 V
P2.03= 13,5 A
P2.04= 50 Hz
P2.05= 2930 rpm
P4.01= 5,0 %
P9.00= 1
P9.01= 10
P9.03= 50
P9.12= 11
P9.13= 1
START
