VYBO Electric Vector V800 - Group P7: Control Panel and Display

Chapter 4: List of function parameters - shorted
69
P6.22
Selection of output
terminal mode
….X: M01 mode
0: Positive logic
1: Negative Logic
…X.: RA-RB-RC mode
0: Positive logic
1: Negative Logic
..X..: Reserved
.X…: Reserved
X….: Reserved
00000
☆
Group P7: Control panel a display
Function
code
Parameter name
Setting range
Default
setting
Attribute
P7.00
Correction power
factor
0.0 - 200.0
100.0
☆
P7.01
Selection of the
function of the JOG
key Only valid for
models V800-
4T0370 to 4T2000
with two-line
display
0:JOG button is disabled on DP6-G-3
panels
1: Switching between panel control and
external control (terminal command
channel or communication channel)
2: Switching between FORWARD and
REVERSE
3: Activation of FORWARD JOG
4: BACKWARD JOG activation
5: Activation of the STOP button on DP6-
E-2 panels
0
P7.02
STOP/RESET
button
0: STOP/RESET key enabled only in
operation panel control
1: STOP/RESET key enabled in any
operation mode
1
☆
