Chapter 4: List of function parameters - shorted
70
Function
code
Parameter name
Setting range
Default
setting
Attribute
P7.03
Parameters 1, LED
display during RUN
0000 - FFFF
Bit00: Frequency of RUN 1 (Hz)
Bit01: Setting of frequency (Hz)
Bit02: Bus voltage (V)
Bit03: Output Voltage (V)
Bit04: Output Current (A)
Bit05: Output power (kW)
Bit06: Output torque (%)
Bit07: Input S status
Bit08: Output status M01
Bit09: FIV voltage (V)
Bit10: FIC voltage (V)
Bit11: Reserved
Bit12: Counter value
Bit13: Length value
Bit14: Display Load Speed
Bit15: PID setting
1F
☆
P7.04
Parameters 2, LED
display during RUN
0000-FFFF
Bit00: PID Feedback
Bit01: PLC status
Bit02: Setting of frequency (kHz)
Bit03: Frequency 2 of operation (Hz)
Bit04: Remaining time of RUN mode
Bit05: FIV voltage before correction (V)
Bit06: FIC voltage before correction (V)
Bit07: Reserved
Bit08: Linear speed
Bit09: Current time under voltage
Bit10: Current time of Run mode (Min)
Bit11: Impulse setting of frequency (kHz)
Bit12: The value of communication
setting
Bit13: Reserved
Bit14: Display of the main frequency X
(Hz)
Bit15: Display of the auxiliary frequency Y
(Hz)
0
☆
