VYBO Electric Vector V800 - Power Terminal Blocks V 800 and Their Description

Chapter 2 Installation and wiring
39
- Switch J2 determines whether the FIC is a voltage 0-10V or a current 4-20 mA input
- Switch J1 determines whether the FOV is a voltage or current 4-20 mA output
- Switch J4 determines whether the source of digital inputs is internal or external
- Switch J3 determines the ON/OFF resistance of the communication line
- CN2 is a 10 PIN port for connecting the display or extension cable to the display
2.3.7 Power terminal blocks and control terminal blocks V 800 and their
description
The arrangement of the terminals of the V 800 power terminal block is as follows:
Terminal designation
Description
R/L1, S/L2, T/L3
Supply voltage (input terminals)
U/T1, U/T2, U/T3
Inverter output terminals for connecting a three-phase electric
motor.
+/B1, -
DC circuit output. WARNING!!!
Only the brake unit can be connected here!
+/B1, B2
Braking resistor connection
+, PR
Braking resistor connection (Equipment type A)
Earthing (PE)
Description of switches on the control panel
Switch name
Description of the switch
J2
FIC analogue input: voltage (0-10 V) input switch to V
FIC analogue input: current (0 - 20 mA) input switch to I
J1
FOC analogue output: voltage (0-10 V) output switch to V
FOC analogue output: current (0 - 20 mA) output switch to I
J3 (0,4 - 30 kW)
Switch J3 determines whether the power source for the digital terminals is
internal or external (Working range from +5V to 27V).
J4 (0,4 - 30 kW)
Switch J3 determines the value of the terminal resistance of the
communication line. Switched ON or switched OFF.
J3 (37 - 200 kW)
Switch J3 determines the value of the terminal resistance of the
communication line. Switched ON or switched OFF.
J4 (37 - 200 kW)
Switch J4 determines whether the power source for the digital terminals is
internal or external (Working range from +5V to +27V).
Prepínač J3 určuje či EMC zapnuté ON alebo vypnuté OFF
CN2
10 PIN port for connecting the display or extension cable to the display
