VYBO Electric Vector V800 - Group C0: Torque Control and Parameter Limitation

Chapter 5: Detailed description of parameters
186
Group C0: Torque control and parameter limitation
C0.00
Selection of control the speed /
torque
Default
0
Setting range
0
Speed control
1
Torque control
It is used to select the inverter control mode: speed control or torque control.
V 800 provides S-terminals with two torque-related functions, "Torque control is disabled"
(function 29) and switching between "Speed control / torque control" (function 46). Both
S-terminals must be used together with C0.00 to perform the speed / torque control
switching. If function 46 (switching speed control / torque control) is assigned to the S-
terminal, it is OFF, the control mode is determined by C0.00. If the S terminal allocated
with function 46 is ON, the control mode is to reverse the value of C0-00.
However, if the torque control function is disabled, the inverter is fixed for operation in
the speed control mode.
C0.01
Torque control source settings
Default
0
Setting range
0
Digital setting (C0.03)
1
FIV
2
FIC
3
Reserved
4
IMPULSE setting, option
5
Communication setting
6
MIN (FIV, FIC)
7
MAX (FIV, FIC)
C0.03
Digital setting of torque
control
Default
150 %
Setting range
-200% - +200%
Parameter C0.01 is used for "Torque Control Source Settings". There are a total of 8
Torque Controllers. The torque setting is the relative value, the value of 100.0%
corresponds to the nominal torque. The adjustment range is from -200.0% to 200.0%,
which means that the maximum torque of the inverter is twice the nominal torque of the
motor.
The torque setting uses 1-7, i.e.. communication interface, analog input and pulse input.
The data format is -100.00% to 100.00%. 100% corresponds to C0.03.
