BA 357-00 * 3.0 * 35700_05_Bedienung.fm 5-83
Operation 5
Pulling out material from slopes
This position allows to pull material out of slopes or roadside ditches with
maximum safety and to spread it as required.
Moving material with longer reach
This position allows to move material without damaging slopes or
structures.
➥ Backfilling with maximum safety and without damaging slopes.
Picking up remaining material
1. Fold up the front half of the bucket (multipurpose bucket).
2. Tilt out the bucket.
3. Lower the bucket to the ground. Ensure that both bucket halves touch
the ground.
4. Close and tilt in the multipurpose bucket at the same time.
5. Raise the bucket with the lift hydraulics.
Both bucket halves must touch the ground so that all
the material is picked up.
