5-98 BA 357-00 * 3.0 * 35700_05_Bedienung.fm
5 Operation
Table for values that have been determined
Enter the values that have been determined in the column “Entry”.
Designation Measure/determine Entry
GN Maximum authorized payload
Enter the calculated values in the load
diagram
– see "Calculation formula for stability (load
diagram)" on page 5-99.
kg/lbs
SN
Position of load center:
pallet forks
Values entered in load
diagram according to ISO 14397-1.
500
600
700
mm (in)
SN
Position of the load centre:
bucket or other attachments
mm (in)
S Stability factor
Refer to table Required safety factors
(S) on page 5-99 for the values.
–
L1
Distance: between center of front
axle and center of gravity
of attachment
Measurement.
mm (in)
L2
Axle base: between center of front
axle and center of rear axle
mm (in)
L3
Distance: between load center
(payload) and center of front axle
mm (in)
GH
Load on rear axle
(without load on loader unit)
Calculated. kg/lbs
F1
Measured load on rear axle
(without attachment, with extended
loader unit)
Determine the weight on scales without
attachment.
kg/lbs
F2
Load reduction on rear axle due to
installed pallet forks/attachment
Calculated, or measured if scales and an
attachment are available.
kg/lbs
GA Weight of pallet forks/attachment
Ask attachment manufacturer.
kg/lbs
SA
Center of gravity of pallet forks/
attachment
–
p
max
Material density of load
Calculated: depends on material
picked up with the bucket.
t/m³
V Bucket capacity (heaped)
Attachment type label,
or ask attachment manufacturer.
m³
M Payload mass Calculated. kg/lbs
