Operation 5
Required safety factors (S)
Calculation formula for stability (load diagram)
Pallet forks DIN EN 474-3
Rough terrain 60 % S = 0.6
Firm and level ground 80% S = 0.8
Bucket ISO 14397-1
– 50 % S = 0.5
F2 =
p
max
=
GH x L2
L3
GN = S x
GN
V
GA x L1
L2
GH = F1 − F2
Affix the maximum authorized material density
in a clearly visible position on the bucket, and
enter it in the Operator’s Manual of the
attachment.
