BA 357-00 * 3.0 * 35700_07_Wartung.fm 7-41
Maintenance 7
Preliminary work
1. Park the machine on firm, level and dry ground.
2. Apply the parking brake.
3. Lower the loader unit to the ground.
4. Switch off motor isolating switch.
5. Turn the machine off and remove the ignition key.
6. Open the battery cover plate.
7. Pull the battery connector A on the strap
horizontally out of the bushing.
8. Loosen the connection B (M8).
Removing the rear part
1. Per side, disconnect one plug-and-socket connection A to
the rear lights.
2. On each side 3, unscrew the screws B.
3. Remove the rear part C from the centering bolts backwards.
Fig. 223
AB
Fig. 224
A
B
C
