8 Malfunctions
3rd control circuit
Error code FMI
Warning
light
Error description Remedy
517040
2
Red
B041 – Potentiometer rocker switch (joystick):
Signal is faulty or irregular
– 3rd control circuit and quickhitch unlocking
mechanism without function
Critical error
1. Turn off the machine and
then turn it on again.
2. If the error occurs again:
have the error corrected by
an authorized service
center.
3 Yellow
B041 – Potentiometer rocker switch (joystick):
Signal range exceeded or short circuit to positive
supply voltage
Error
1. Turn off the machine and
then turn it on again.
2. If the error occurs again:
have the error corrected by
an authorized service
center.
4 Yellow
B041 – Potentiometer switch (joystick):
Signal range fallen below or short circuit to
positive vehicle ground / sensor ground
28 Yellow
B041 – Potentiometer switch (joystick):
Open control circuit or short circuit to positive
supply voltage
517122
3 Yellow
D002 – Potentiometer rocker switch (joystick):
Signal range exceeded or short circuit to positive
supply voltage
4 Yellow
D002 – Potentiometer switch (joystick):
Signal range fallen below or short circuit to
positive vehicle ground / sensor ground
28 Yellow
D002 – Potentiometer switch (joystick):
Open control circuit or short circuit to positive
supply voltage
518981
3 Yellow
S033 – Switch continuous operation:
Signal range exceeded or short circuit to positive
supply voltage
– Continuous functioning of 3rd control circuit
without function
26 Yellow
S033 – Switch continuous operation:
Signal outside of the valid range
– Continuous functioning of 3rd control circuit
without function
27 Yellow
S033 – Switch continuous operation:
Open circuit or short circuit to ground
– Continuous functioning of 3rd control circuit
without function
519919
3
R019-Potentiometer:
signal range exceeded or short circuit to positive
supply voltage
27
R019-Potentiometer:
open circuit or short circuit to ground
