TROUBLESHOOTING
Inputs on the Operator (for SpeedGate models introduced PRIOR to 2021 - FEIG Gen I)
Input FEIG I Terminal(s) LCD Display
External Stop 1 1 & 2 F.211 External Stop 1 tripped
External Stop 2 3 & 4 F.212 External Stop 2 tripped
Open Input 6 Open Input T06
Close Input 8 Close Input T08
Infrared Beam Input 12 Photo Eye Input T12
Stop 14 Stop Input T14
Loop Safety Input 18 Stop Input T18
Loop Close Input 20 Close Input T20
Inputs on the Operator (for SpeedGate models introduced in 2021 - FEIG Gen II)
Input FEIG II Terminal(s) LCD Display
External Stop 1 41 & 42 F.211 External Stop 1 tripped
External Stop 2 31 & 32 F.212 External Stop 2 tripped
Open Input 52 Open Input 1
Close Input 53 Stop Input 2
Infrared Beam Input 75 Photo Eye Input 5
Stop 54 Close Input 3
Loop Safety Input 64 Stop Input 9
Loop Close Input 65 Close Input 10
For a complete list of faults, refer to the following fault log.
The cause of the fault must be resolved rst before the corresponding message is acknowledged.
To acknowledge an error and clear it from the LCD screen (i.e., RESET), use the foil
keypad buons (UP arrow, DOWN arrow, STOP buon) which are located to the
right of the LCD display:
FEIG GEN II models (introduced 2021) Hold UP arrow + DOWN arrow + STOP buon simultaneously
for approximately ve (5) seconds.
FEIG GEN I models (prior to 2021) Press the STOP buon and hold for approximately ve (5)
seconds.
