W&T UDP bus mode
Subject to error and alteration
14�1�1 Configuring the local port number
A UDP port number must be set on both the master as well
as the slave Com-Servers. The contents of all UDP datagrams
addressed to the Com-Server and this UDP port number are
received and their data forwarded to the serial device.
SETUP Port x
TCP/IP Mode
...
Port List
...
Local Port TCP/UDP
14�1�2 Configuring the destination parameters
SETUP Port x
TCP/IP Mode
...
UDP Client
...
Server Port
Server IP/URL
Configuration on the UDP bus master
n
Server port
Port number that was configured as a local port number
for the UDP Bus slaves.
Format: decimal
n
Server IP/URL
To ensure sending of the UDP datagrams as broadcasts,
configure the broadcast address 255.255.255.255 here.
Configuration on the UDP bus slave
n
Server port
Port number that was configured as a local port number
for the UDP Bus master.
Format: decimal
