W&T Box-to-Box mode
Subject to error and alteration
16�1�1 Configuring Box-to-Box mode
1
Only the Master port is configured for „Box to Box“
mode;Slave ID address, slave port number as well as any
use of TLS encryption are configured only on the master port!
Settings in the Special Options submenu and parameterizing
of the serial port can and must be done on both ports (see
examples at the end of this section).
SETUP Port x
TCP/IP Mode
...
Box to Box
...
Slave Port
Slave IP
n Slave Port (set only for master port)
Port of the serial Com-Server Slave port. The following port
numbers are pre-configured at the factory:
• Port A = 8000 (all models with only one serial port)
• Port B = 8100
• Port C = 8200
• Port D = 8300
n Slave IP-Address (set only for master port)
IP address of the Com-Server in which the Slave port is
located.
Once you have entered all the parameters in the Com-Server
port menu, press the ENTER key several times to return to
the main menu and save the entries with SAVE Setup. The
message Saving... appears, then Box to Box mode is activated.
The entry Box to Box Master now appears in the SETUP Port x
r Port State r Connection State menu. The connection sta-
tus can be read at any time in this menu both for the Master
and for the Slave port. In addition, both Status LEDs for the
respective Com-Server ports begin to flash cyclically at appro-
ximately 1x a second.
