W&T Appendix
Technical data and formfactor 58665
Supply voltage ���
Power-over-Ethernet
External supply...
... DC
... AC
37 - 57V DC from PSE
12 - 48V DC (+/- 10%)
18 - 30Vrms +/- 10%)
Current draw typ. 55mA @ 24VDC
PoE Class 1 (0,44 - 3,84W)
Permissible ambient temperatur ���
... storage
... operation
-40 ... +70°C
0 ... +60°C
Permissible relative humidity 0 ... 95% (not condensing)
Network 10/100BaseT, RJ45 for STP cables
Galvanic Isolation Network: 1,5kV rms
Dimensions approx. 105 x 75 x 22mm,
Weight approx. 150g
Serial ports 1 x RS232/422/485 configurable,
DB9/Male
Baud rates 50 bis 230.400 kBit/s
Data formats 7, 8 daten bits, 1, 2 stop bits
NO, EVEN, ODD Parity
Flow control Hardware handshake or
Xon/Xoff protocol
Front view 58661, 58665 Bottom side 58661, 58665
Serial Port
Power
Network
Status
17
75
23
108
Error
Measure in mm. +/-1mm
