W&T Com-Server++ - Optional Settings

120
W&T UDP bus mode
n Server IP/URL
If the UDP datagrams need to be sent addressed to the
UDP Bus master, enter here the IP address of the UDP Bus
master. TO also send in this direction via broadcast, confi-
gure here broadcast address 255.255.255.255.
14�1�3 Optional settings
Serial transmission parameters
SETUP Port x
UART Setup
...
Baud, Parity, Data Bits,
Stopbits, Handshake
Baud rate, data bits, parity and handshake procedure must
conform to the connected serial device. For details see section
Configuration of the Serial Port.
Packeting options for serial receive data
SETUP Port x
TCP/IP Mode
...
UDP Client
Special Options
System Options
Packet Options
Activ. Packet Options
When sending serial protocols such as Modbus/RTU, it is of-
ten necessary to send serial received datagrams also closed
on the network side in a TCP packet. The menu paths shown
above offer various ways to parameterize serial packet limits
(pause times, start-/end sequences, datagram lengths) and to
activate their processing for the respective mode. Details can
be found in the section Packeting of serial datagrams.
