W&T Appendix
Used ports and network security
The port numbers factory set in the Com-Server:
Port-/Socket-
number Application
-
Password-
protection? configurable?
8000 (TCP) Socket server port A no yes
8100, 21 (TCP) Socket server port B no yes
8200 (TCP) Socket server Port C no yes
1111 (TCP) Telnet configuration port yes yes
9094 (TCP) Control port Port A yes yes
9194 (TCP) Control port Port B yes yes
9294 (TCP) Control port Port C yes yes
9084 (TCP) Reset port status port A yes yes
9184 (TCP) Reset port status port B yes yes
9284 (TCP) Reset port status port C yes yes
8888 (TCP) Reset Com-Server yes yes
8002 (TCP)17 Initialize firmware update yes yes
8003 (TCP) Read configuration data yes yes
8004 (TCP) Write configuration data yes yes
8513 (UDP) Inventory no yes
161 (UDP) SNMP yes yes
The following port numbers are deactivated with the factory
defaults. They will be used if Web Based Management is acti-
vated or in case of a firmware update.
Port-/Socket-
number Application
-
Password-
protection? Configurable?
80 (TCP) Web-Based-Management yes yes
69 (UDP) Firmware update yes no
1
Each port number may be used for just one service
in the Com-Server. If differing numbers are used for
changeable ports, be sure that these are not assigned in du-
plicate.
