W&T Supply voltage
Subject to error and alteration
3�1 Supply voltage 58662
The model 58662 Com-Server can be powered using the plug-
in screw terminal located on the lower section of the housing.
The input is reverse polarity protected and may be used with
AC or DC voltages having the following specifications:
The current draw can be found in the technical appendix.
• AC: 9Veff (- 10%) - 30Veff (+10%)
• DC: 12V (-10%) - 48V (+10%)
L+M
+12-48V DCGND
