Ordinary and extraordinary maintanance
7
fig 7.3.2 i - Unplug the connector fig 7.3.2 l - Removing the air filter hose
8. Unplug the extruder connector from outside the machine (fig 7.3.2 i)
9. Remove the air filter hose by gently pulling (fig 7.3.2 )
10. Unscrew the cover panel (fig 7.3.2 m)
11. Remove the cover panel (fig 7.3.2 n)
12. Remove the connector from inside the machine (fig 7.3.2 o)
13. Remove the extruder from the machine (fig7.3.2 p)
