June 11, 2015, 715004754 Rev. A
Page 47
To change the IEEE-488 address:
1. Press Shift, Config.
2. On the Configuration page, use the arrow keys to locate the IEEE address
selector box.
3. Enter the number corresponding to the desired IEEE-488 address, and then
press Enter.
Requirement: IEEE-488 addresses must be unique for each instrument in an
Alliance HPLC system, and they must be between 2 and 29. Your Alliance HPLC
system can require that the IEEE-488 address for the 2414 RI detector be
greater than that for other devices in the system. Consult your data system or
controller operator's manual for more information on IEEE-488 communications.
4. To exit the configuration functions, press Home.
3.3.3 Connecting to a manual injector
If you are using a manual injector with your IEEE-488 system, connect the signal
cables from the detector’s rear panel connector to the injector as shown in the table
below.
For information on injection trigger signals from a manual injector, see “Connecting
injection trigger signals” on page 52.
3.4 Analog-out/event-in (I/O) connections
To connect the detector to instruments not using a digital communications interface
(that is, neither Ethernet nor IEEE-488), you use the analog-out/event-in (I/O)
connectors on the rear panel.
This section describes signal connections between the 2414 RI detector’s
analog-out/event-in connectors and the following components:
• Waters Alliance e2695 separations module in No Interaction mode
• Waters eSAT/IN module
• Waters (or other) manual injector
• Other manufacturer’s integrator or A/D interface device
Table 3–2: 2414 RI detector connections to a manual injector
Detector (connector A) Manual injector
Inject Start + (red) One set of spade-lug Inject Start terminals
Inject Start – (black)
Warning: To avoid electrical shock, power-off the detector before making any
electrical connections.
