Number of sample plates Total of two plates:
• 96 and 384 microtiter plates
• 48 position 2.00-mL vial plates
• 48 position 0.65-mL micro-centrifuge tube plates
• 24 position 1.50-mL micro-centrifuge tube plates
Maximum sample capacity 768 in two 384-well plates.
Injection volume range 0.1 to 50.0 μL, in 0.1-μL increments; 10-μL loop is standard.
Injection mode Partial loop uses Needle Overfill Mode (default mode) used
for optimal quantitation using partial-loop injection volumes.
Sample delivery precision <1% peak area RSD within 20% to 75% of loop volume for
10-μL loops, UV detection.
Injection linearity >0.999 coefficient of deviation (from 20% to 75%) based on
peak area.
Wash solvents Two degassed: strong solvent and weak wash solvent,
programmable to suit the application.
Sample temperature range 4.0 to 40.0 °C, settable in 0.1 °C increments (assumes an
ambient temperature of 25.0 °C). At an ambient temperature
of 21.0 °C or lower, the SM-FL will maintain the temperature
of the sample compartment down to 4.0 °C with a tolerance
of −2.0/+4.0 °C, when configured with the maximum number
of vials and plates.
Temperature accuracy ±0.5 °C
Temperature stability ±1.0 °C
Sample carryover <0.005% or <2.000 nL, whichever is greater.
Table B–17: SM-FL Input/output specifications
Feature Specification
Run stopped output • Maximum voltage: 30 VDC
• Maximum current: 0.5 A
• Maximum VA rating: 10 W
• Contact resistance (nominal): 0.2 ohms
• Screw terminal connector
Behavior: If an error message exists, the switch closes, and
then opens when the error is cleared.
Stop flow input TTL signal or contact closure:
• Input voltage range: ±30 VDC
• Logic High: ≥3.0 VDC
• Logic Low: ≤1.9 VDC
• Minimum pulse width: 100 msec
• Screw terminal connector
Table B–16: SM-FL performance specifications
Feature Specification
