November 16, 2016, 715004521 Rev. C
Page 96
B.4 ccBSM specifications
Table B–7: ccManager
Ceramic PEEK blend
Diamond-like coating PPS
Flouroelastomer 316 stainless steel
Fluoropolymer UHMWPE blend
Gold
Vespel
®
Nitronic 60 Zirconia
PEEK
Table B–8: CM-30S
316 stainless steel PEEK
Diamond-like coating
Table B–9: SM-FL
Diamond-like coating PEEK
Fluoroelastomer PPS
Fluoropolymer PPS Alloy
Gold 316 stainless steel
PEEK blend Titanium alloy
Table B–10: ccBSM performance specifications
Feature Specification
Number of solvents (co-solvent
pump only)
Liquid CO
2
on the A side of the pump. The CO
2
high-pressure inlet connects to the rear panel of the
ccManager.
As many as four co-solvents on the B side of the pump,
labeled B1, B2, B3, and B4.
Priming No priming needed on the A side pump for CO
2
solvent:
The CO
2
inlet pressure from the ccManager is typically
between 750 and 1200 psi, not to exceed 1300 psi.
Prime only the B side of the pump (co-solvents). Wet
priming can run at flow rates up to 4 mL/min.
Leak management Drip trays manage all leaks from the pump into a drain tube
that is directed either to the front or rear of the module
where it empties into a waste container.
