Waters ACQUITY UPC2 - ACQUITY UPC2 Core System Stack Configurations and Supported Modules

November 16, 2016, 715004521 Rev. C
Page 15
1.2.1 ACQUITY UPC
2
core system stack configurations and
supported modules
Figure 1–2: Core 1 configuration (2-column system)
Figure 1–3: Core 2 configuration (4-column system)
73
PDA
CM-A
ccManager
SM-FL
ccBSM
Side mount
solvent tray
TP03523
ccManager
SM-FL
ccBSM
Solvent
tray
PDA
CM-AUX
CM-A
