B.10 Physical specifications
Review the physical instrument module specifications and observe all safety advisories.
Note: The ACQUITY UPC
2
System requires a rear clearance of at least 15 cm (6 in).
Warning: To avoid back injuries, do not attempt to lift the devices without assistance.
Table B–18: ccBSM
Attribute Specification
Height 22.9 cm (9 inches)
Width 34.3 cm (13.5 inches)
Depth 66 cm (26 inches)
Weight 33 kg (less than 75 pounds)
Table B–19: CM-A
Attribute Specification
Height 19.9 cm (7.8 inches)
Width 34.3 cm (13.5 inches)
Depth 61.0 cm (24.0 inches)
Weight 20.9 kg (46.0 pounds)
Table B–20: CM-AUX
Attribute Specification
Height 13.7 cm (5.4 inches)
Width 34.3 cm (13.5 inches)
Depth 61.0 cm (24.0 inches)
Weight 11.4 kg (25.0 pounds)
Table B–21: CM-30S
Attribute Specification
Height 71.9 cm (28.3 inches)
Width 23.6 cm (9.3 inches)
Depth 61.5 cm (24.2 inches)
Weight 43.1 kg (95.0 pounds)
