Figure 5–13: Splitter bracket mount location on the PDA
Figure 5–14: Splitter bracket mount location on the 515 makeup pump
5.3 Core 1 configuration: system diagrams and tubing
connections
Note: The figures in this section describe recommended splitter bracket mounting locations. If you
choose other locations to mount the splitter assembly bracket, ensure that the splitter tubing
connections are not pinched or constrained, and that you follow safe laboratory practices for leak
containment.
515 makeup
pump
Splitter
bracket
