Waters ACQUITY UPC2 - ACQUITY UPC 2 Photodiode Array Detector Specifications; Sample Manager - Fixed Loop Specifications

November 16, 2016, 715004521 Rev. C
Page 101
B.8 ACQUITY UPC
2
Photodiode array detector
specifications
B.9 Sample manager - fixed loop specifications
Table B–15: PDA performance specifications
Item Specification
Data rate ≤ 80 Hz, maximum
Digital filter Variable with data rate
Digital resolution 1.2, 2.4, 3.6, 4.8, 6.0, 7.2, 8.4, 9.6, 10.8, 12.0 nm
Drift
a
(dry)
a. ASTM drift tests require a temperature change of less than 2 °C/hour (3.6 °F/hour) over a one hour period. Larger
ambient changes will result in larger drift. Better drift performance depends on better control of temperature fluctuations.
To realize the highest performance, minimize the frequency and the amplitude of temperature changes to below
1 °C/hour (1.8 °F/hour). Turbulences around one minute or less can be ignored.
≤1000 µAU/hr (at 230 nm, 2 Hz, 1 sec TC, 3.6 nm res, dry
analytical flow cell); 2 hr warm-up, environmental stability <±2
°C/hr variation
Linearity ≤5% at 2.0 AU, propylparaben series at 257 nm, 10 mm
analytical flow cell
Nitrogen purge Purge fitting present on optics bench and rear panel
Noise (wet) <10 µAU (254 nm, 2 Hz, 1 sec TC, 3.6 BW res, 10 mm analytical
flow cell) flow rate 0.5 mL/min, 90:10 H
2
O:acetonitrile
Optical resolution 1.2 nm (nominal), with 50-µm slit
Order filter Fixed, 370 nm to 800 nm
Photodetector 512 element selective access photodiode array
Wavelength accuracy ±1.0 nm (tested with Erbium Perchlorate)
Wavelength calibration filter Erbium filter, used at startup or on-demand
Wavelength range 190 to 800 nm
Wavelength repeatability ±0.1 nm
Table B–16: SM-FL performance specifications
Feature Specification
Integrated leak management Leak sensors, as standard, and safe leak handling. Drip
trays direct all leaks to the front of the instrument, and then
into the waste line.
Operating flow rate range 0.010 to 4.000 mL/min, in 0.001 mL increments.
Maximum operating pressure 41,369 kPa (413 bar, 6000 psi) up to 3.25 mL/min.
pH range pH 2 to 12.
Unattended operation Leak sensors, full 96-hour diagnostic data display through
the console software.
