4 External connections
A Waters Technical Service representative unpacks and installs your ACQUITY UPC
2
system modules.
See also: The ACQUITY UPC
2
System Site Preparation Guide.
Requirements:
• Contact Waters’ Technical Service department before moving the ACQUITY UPC
2
system modules.
• If you must transport a system component, or remove it from service, contact Waters’
Technical Service department for recommended cleaning, flushing, and packaging
procedures.
The information in this chapter explains how to connect the power cables, Ethernet cables,
and external input/output cables on the rear panels of the system modules.
Warning: To avoid back injuries, do not attempt to lift the system modules without
assistance.
