November 16, 2016, 715004521 Rev. C
Page 52
5.2 Splitter bracket mount locations
Figure 5–9: Splitter bracket mount location on the SM-FL
Figure 5–10: Splitter bracket mount location on the CM-A
TP03510
ccManager
SM-FL
Bottle tray
bracket
Splitter
bracket
TP03511
ccManager
Bottle tray
bracket
Splitter
bracket
Column
manager
