Waters ACQUITY UPC2 - Page 51

November 16, 2016, 715004521 Rev. C
Page 51
Figure 5–7: ISM splitter module for dual detection
Figure 5–8: ISM splitter module for triple detection
From the PDA
To the ccManager
QDa
detector
0.010 inch ID PEEK
0.007 inch ID
PEEK
1
2
From the PDA
To the
ccManager
0.010 inch ID
PEEK
0.007 inch ID
PEEK
To the
ELSD
75 µm ID
PEEKsil™
QDa detector
probe
1
3
2
