November 16, 2016, 715004521 Rev. C
Page 94
Table B–3: Electrical specifications
Feature Specification
Protection class Class I: The insulating scheme used in the instrument to
protect from electrical shock. Class I identifies a single level of
insulation between live parts (wires) and exposed conductive
parts (metal panels), in which the exposed conductive parts are
connected to a grounding system. In turn, this grounding
system is connected to the third pin (ground pin) on the
electrical power cord plug.
Overvoltage category Class II: Pertains to instruments that receive their electrical
power from a local level such as an electrical wall outlet.
Pollution degree 2: A measure of pollution on electrical circuits that can produce
a reduction of dielectric strength or surface resistivity. Degree 2
refers only to normally nonconductive pollution. Occasionally,
however, expect a temporary conductivity caused by
condensation.
Moisture protection Normal (IPXO): IPXO means that no Ingress Protection
against any type of dripping or sprayed water exists. The “X” is
a placeholder that identifies protection against dust, if
applicable.
Line voltages, nominal
Grounded AC.
Line voltage range 100 to 240 Vac.
Frequency
UPC
2
System and its modules: 50−60 Hz
Maximum power draw • ccBSM: 200 VA
• CM-A with active pre-heater: 400 VA
• CM-30S: 600 VA
• ccManager: 200 VA
• PDA: 185 VA
• SM-FL: 400 VA
Table B–4: Environmental specifications
Feature Specification
Acoustic noise <65 dBA (single-stack, 5-module system)
Operating temperature range 15 to 28 °C (59 to 82.4°F)
Operating humidity 20 to 80%, non-condensing
Transportation and storage temperature −30 to 60 °C (−22 to 140 °F)
Transportation and storage humidity 10 to 85%, noncondensing
Shock (drop) per ASTM D 4169-90
Vibration per ASTM D 4169-90
