CFW500 | 165
Appendix B - Anexo B
Appendix B
Anexo B
Table B.6: Conducted and radiated emission levels, and additional information
Tabla B.6: Niveles de emisión conducida y irradiada y informaciones adicionales
Tabela B.6: Níveis de emissão conduzida e radiada e informações adicionais
Inverter Model (with build-in RFI filter)
Modelo del Convertidor de Frecuencia
(con filtro RFI interno)
Modelo do Inversor (com Filtro RFI Interno)
Conducted Emission - Maximum Motor Cable Length
Emisión Conducida - Longitud Maxima del Cable del Motor
Emissão Conduzida - Comprimento Máximo do cabo do Motor
Radiated Emission
Emisión Radiada
Emissão Radiada
Category C3
Categoría C3
Categoria C3
Category C2
Categoría C2
Categoria C2
Category
Categoría
Categoria
1 CFW500A01P6S2...C2... 30 m (1182 in) 11 m (433 in) C3 2 CFW500A02P6S2...C2... 30 m (1182 in) 11 m (433 in) C3 3 CFW500A04P3S2...C2... 30 m (1182 in) 11 m (433 in) C3 4 CFW500A07P0S2...C3... 6 m (236 in) - C3 5 CFW500B07P3S2...C2... 30 m (1182 in) 11 m (433 in) C3 6 CFW500B10P0S2...C2... 30 m (1182 in) 11 m (433 in) C3 7 CFW500A01P0T4...C2... 20 m (787 in) 11 m (433 in) C3 8 CFW500A01P6T4...C2... 20 m (787 in) 11 m (433 in) C3 9 CFW500A02P6T4...C2... 20 m (787 in) 11 m (433 in) C3
10 CFW500A04P3T4...C2... 20 m (787 in) 11 m (433 in) C3
11 CFW500A06P1T4...C3... 6 m (236 in) - C3
12 CFW500B02P6T4...C2... 6 m (236 in) 6 m (236 in) C3
13 CFW500B04P3T4...C2... 6 m (236 in) 6 m (236 in) C3
14 CFW500B06P5T4...C2... 6 m (236 in) 6 m (236 in) C3
15 CFW500B10P0T4...C3... 20 m (787 in) - C3
16 CFW500C14P0T4...C2... 30 m (1182 in) 20 m (787 in) C3
17 CFW500C16P0T4...C2... 30 m (1182 in) 20 m (787 in) C3
18 CFW500D28P0T2...C3... 5 m (196 in) - C3
19 CFW500D33P0T2...C3... 5 m (196 in) - C3
20 CFW500D47P0T2...C3... 5 m (196 in) - C3
21 CFW500D24P0T4...C3... 5 m (196 in) - C3
22 CFW500D31P0T4...C3... 5 m (196 in) - C3
23 CFW500E56P0T2...C3... 10 m (394 in) - C3
24 CFW500E39P0T4...C3... 5 m (196 in) - C3
25 CFW500E49P0T4...C3... 5 m (196 in) - C3
26 CFW500F77P0T4...C3... TBD TBD TBD
27 CFW500F88P0T4...C3... TBD TBD TBD
28 CFW500F0105T4...C3... TBD TBD TBD
