168 | CFW500
Appendix B - Anexo B
Appendix B
Anexo B
Table B.7: Output current specification as a function of the frequency switching to CFW500
Tabla B.7: Especificación de la corriente de salida en función de la frecuencia de conmutación para el
CFW500
Tabela B.7: Especificação da corrente de saída em função da frequência de chaveamento para o
CFW500
Inverter Model
Modelo del Convertidor
Modelo do Inversor
2.5 KHz 5.0 KHz 10.0 KHz 15.0 KHz
CFW500A01P6B2... 1.6 A 1.6 A 1.6 A 1.6 A
CFW500A01P6S2... 1.6 A 1.6 A 1.6 A 1.6 A
CFW500A02P6B2... 2.6 A 2.6 A 2.6 A 2.6 A
CFW500A02P6S2... 2.6 A 2.6 A 2.6 A 2.6 A
CFW500A04P3B2... 4.3 A 4.3 A 3.5 A 2.8 A
CFW500A04P3S2... 4.3 A 4.3 A 3.5 A 2.8 A
CFW500A07P0S2... 7.0 A 7.0 A 5.8 A 4.9 A
CFW500A07P0T2... 7.0 A 7.0 A 5.8 A 4.9 A
CFW500A09P6T2... 9.6 A 9.6 A 8.0 A 6.7 A
CFW500B07P3S2... 7. 3 A 7.3 A 6.1 A 5.1 A
CFW500B10P0S2... 10 A 10 A 8.0 A 6.5 A
CFW500B07P3B2... 7.3 A 7.3 A 6.1 A 5.1 A
CFW500B10P0B2... 10 A 10 A 8.0 A 6.5 A
CFW500B16P0T2... 16 A 16 A 12.7 A 10.1 A
CFW500D28P0T2... 28 A 28 A 22 A 18 A
CFW500D33P0T2... 33 A 33 A 26 A 21 A
CFW500D47P0T2... 47 A 47 A 36 A 30 A
CFW500E56P0T2... 56 A 56 A 43 A 33 A
CFW500A01P0T4... 1.0 A 1.0 A 1.0 A 1.0 A
CFW500A01P6T4... 1.6 A 1.6 A 1.6 A 1.6 A
CFW500A02P6T4... 2.6 A 2.6 A 2.6 A 2.0 A
CFW500A04P3T4... 4.3 A 4.3 A 2.9 A 2.0 A
CFW500A06P1T4... 6.1 A 6.1 A 4.3 A 3.1 A
CFW500B02P6T4... 2.6 A 2.6 A 2.6 A 2.0 A
CFW500B04P3T4... 4.3 A 4.3 A 2.9 A 2.0 A
CFW500B06P5T4... 6.5 A 6.5 A 4.5 A 3.3 A
CFW500B10P0T4... 10 A 10 A 6.5 A 4.3 A
CFW500C14P0T4... 14 A 14 A 10 A 7.0 A
CFW500C16P0T4... 16 A 16 A 10 A 7.0 A
CF W500D24P0T4.. 24 A 24 A 15 A 12 A
CFW500D31P0T4... 31 A 31 A 16 A 13 A
CFW500E39P0T4... 39 A 39 A 30 A 19 A
CFW500E49P0T4... 49 A 49 A 30 A 20 A
CFW500C01P7T5... 1.7 A 1.7 A 1.7 A 1.7 A
CFW500C03P0T5... 3.0 A 3.0 A 3.0 A 3.0 A
CFW500C04P3T5... 4.3 A 4.3 A 4.3 A 4.3 A
CFW500C07P0T5... 7.0 A 7.0 A 7.0 A 7.0 A
CFW500C10P0T5... 10 A 10 A 9.0 A 7.0 A
CFW500C12P0T5... 12 A 12 A 9.0 A 7.0 A
