42 | CFW500
Optional Kits and Accessories
English
The accessories are incorporated to the inverters in an easy and quick way by using the
concept "Plug and Play". When an accessory is connected to the inverter, the control circuitry
identifies the model and informs the code of the accessory connected in parameter P0027. The
accessory must be installed or modified with the inverter with no input voltage applied. They
may be ordered separately, and are sent in their own package containing the components and
manuals with detailed instructions for their installation, operation and setting.
Table 7.1: Accessory models
WEG Item Name Description
Control Accessories
14741859 CFW500-IOS Standard Plug-in module
14742006 CFW500-IOD Input and output Plug-in module (I/O) digital
14742129 CFW500-IOAD Input and output Plug-in module (I/O) digital and analog
14742003 CFW500-IOR Digital output communication Plug-in module relay
14742001 CFW500-CUSB USB communication Plug-in module
14741999 CFW500-CCAN CAN communication Plug-in module
14742005 CFW500-CRS232 RS232 communication Plug-in module
14742132 CFW500-CRS485 RS485 communication Plug-in module
14742131 CFW500-CPDP Profibus communication Plug-in module
12443605 CFW500-CPDP2 Profibus communication Plug-in module
12619000 CFW500-ENC Encoder input module
(1)
12892814 CFW500-CETH-IP EtherNet/IP communication Plug-in module
12892815 CFW500-CEMB-TCP Modbus TCP communication Plug-in module
12892816 CFW500-CEPN-IO Profinet IO communication Plug-in module
Flash Memory Module
11636485 CFW500-MMF Flash Memory Module
External HMI
11833992 CFW500-HMIR Serial remote HMI
12330016 CFW500-CCHMIR01M 1 m serial remote HMI cable kit
12330459 CFW500-CCHMIR02M 2 m serial remote HMI cable kit
12330460 CFW500-CCHMIR03M 3 m serial remote HMI cable kit
12330461 CFW500-CCHMIR05M 5 m serial remote HMI cable kit
12330462 CFW500-CCHMIR75M 7.5 m serial remote HMI cable kit
12330463 CFW500-CCHMIR10M 10 m serial remote HMI cable kit
Mechanical Accessories
11527460 CFW500-KN1A
(2)
Nema1 kit for frame size A (standard for option N1)
11527459 CFW500-KN1B
(2)
Nema1 kit for frame size B (standard for option N1)
12133824 CFW500-KN1C
(2)
Nema1 Kit for frame size C (standard for option N1)
12692970 CFW500-KN1D
(2)
Nema1 kit for frame size D (standard for option N1)
13104601 CFW500-KN1E
(2)
Nema1 kit for frame size E (standard for option N1)
14601107 CFW500-KN1F
(2)
Nema1 kit for frame size F (standard for option N1)
11951056 CFW500-KPCSA
(2)
Kit for power cables shielding - frame size A
11951108 CFW500-KPCSB
(2)
Kit for power cables shielding - frame size B
12133826 CFW500-KPCSC
(2)
Kit for power cables shielding - frame size C
12692971 CFW500-KPCSD
(2)
Kit for power cables shielding - frame size D
13055389 CFW500-KPCSE
(2)
Kit for power cables shielding - frame size E
146 01158 CFW500-KPCSF
(2)
Kit for power cables shielding - frame size F
12473659 - Ferrite core M-049-03 (MAGNETEC)
12480705 - Ferrite core B64290-S8615-X5 (EPCOS)
12983778 - Ferrite core T60006-L2045-V101
(1) The CFW500-ENC accessory must be only used with the main software version equal to or above the version 2.00.
(2) The Nema1 kit and KPCS Kit cannot be installed simultaneously on the product.
