Table 7.2: I/O configurations of plug-in modules
Plug-In
Module
Functions
DI AI ENC AO DOR DOT USB CAN RS232 RS485 Profibus EtherNet
Source
10 V
Source
24 V
CFW500-IOS 4 1 - 1 1 1 - - - 1 - - 1 1
CFW500-IOD 8 1 - 1 1 4 - - - 1 - - 1 1
CFW500-IOAD 6 3 - 2 1 3 - - - 1 - - 1 1
CFW500-IOR 5 1 - 1 4 1 - - - 1 - - 1 1
CFW500-CUSB 4 1 - 1 1 1 1 - - 1 - - 1 1
CFW500-CCAN 2 1 - 1 1 1 - 1 - 1 - - 1 1
CFW500-CRS232 2 1 - 1 1 1 - - 1 1 - - - 1
CFW500-CRS485 4 2 - 1 2 1 - - - 2 - - 1 1
CFW500-CPDP 2 1 - 1 1 1 - - - 1 1 - - 1
CFW500-CPDP2 2 1 - 1 1 1 - - - 1 1 - - 1
CFW500-ENC500 5 1 1 1 3 1 - - - 1 - - - 1
CFW500-CETH-IP 2 1 - 1 1 1 - - - 1 - 1 - 1
CFW500-CEMB-TCP 2 1 - 1 1 1 - - - 1 - 1 - 1
