Wisi Chameleon Installation Guide

©WISI Communications 2015, Subject to technical changes and misprints
65
www.
www.wisi.de
11.3 Add EMM connection to the output(s)
Connecting an EMM Generator to an output
In SERVICE MANAGEMENT, for an output, click the menu
icon, , and under Simulcrypt >, select the EMMG to
connect the output to.
EMM information and EMMg removal
An output connected to an EMMg will have a Simulcrypt entry
under Settings. To remove an EMMg,connection, click the
menu icon, , and select Remove.
11.4 Add ECM Generator connections
The CA Server set-up for EMM and ECM generation is not covered by this manual. Please contact your CAS supplier
for information.
Adding an ECM Generator connection
In the Simulcrypt menu under SETTINGS, click ADD ECM under the ECM Generators box.
1. Enter a name for the ECMg (internal name/identifier, default name ECMg 1 is OK)
2. Enter the Super CAS ID (info from CAS supplier). The Super CAS ID should be entered as a hex number, but
without the 0x prefix. As an example, if the Super CAS ID is given as 0x320011ac, you should enter 320011ac in the
UI.
3. Enter the HOST ADDRESS, the IP address for the CAS (information from your CAS supplier)
4. Enter the PORT (information from your CAS supplier)
5. For Interface, select a Simulcrypt enabled interface in the drop-down list, or use Auto. If you use Auto, the
Chameleon will try to connect using one interface at the time, and connection will be based on CAS IP address and
port.
6. Click the “yellow tick” .

Wisi Chameleon Specifications

General

Frequency Range	47 - 862 MHz
Power Supply	230 V AC, 50 Hz
Operating Temperature	-20°C to +50°C
Noise Figure	5 dB
Connectors	F-type
